500L Two Vessel Brewhouse
Capacity：5HL/5BBL per brew
Configuration：
Option 1: Mash tun/lauter tun+kettle/whirlpool tank
Option 2: Mash tun+lauter tun+kettle/whirlpool tank
Option 3: Mash/boiling tank+lauter/whirlpool tank
Heating method: Steam/electric/gas heating
Structure：Pre assembled or skid mounted
Water system: 10-15HL hot water tank
Control unit: PID control panel or PLC panel
Material: SUS304/304L
The 5hl brewhouse is more used for brewpubs and the small capacity breweries.
The system designed by ZYB is easy to operate and meanwhile always with good guarantee on beer brewing quality.
It is more customized as the preference of different brewers request. We make the whole brewhouse unit designed on skid or being flexible as special layout request. It is an option which does not take much space in the pub or micro brewery, and therefor leaving more space for guest area etc.
Small floor plan
Easy to operate
Flexible on different customization
A big plato range as different recipe request.
Flexible heating method as facility request.
500L-Two Vessel-Automatic Brewhouse system | |||
Brewhouse | |||
Mash/Lauter tun | 5HL/5BBL | 1 pc | Cone or domed seal top Tor stir with shaft connector to lower twist force Support leg wit adjustable leg bolts |
Kettle/whirlpool tank | 5HL/5BBL | 1 pc | Cone or domed seal top Tangent wort inlet Two clean wort outlet Support leg wit adjustable leg bolts |
Heat exchanger | 40HL/H | 1 set | Double stage, with aeration unit |
Lauter pump | 1m³/h | 1 set | Centrifugal pump, VFD control |
Mash/wort pump | 3m³/h | 1 set | Centrifugal pump, VFD control |
Steam condenser | DN200 | 1 set | Installed with kettle for wort condensing With spray nozzles Cold water spraying while boiling process. |
Wort grant | 10L | 1 set | Visible glass |
Valves&piping | DN32 | Assorted | Manual butterfly valve Quantity as exact brewing process design. |
Water station | |||
Hot water tank | 10HL | 1 pc | Material: SUS304 Insulated on top, cylinder, bottom Heating method: Steam jacket; Steam coil Hot water storage from wort cooling. Optional: Three times of Brewhouse capacity. |
Hot water pump | 3m³/h | 1 set | Centrifugal pump SS304L pump head Optional: Extra backup pump for efficiency or in case of maintaining. |
Control system | |||
Main Control panel | 1 set | Stainless steel material, IP55/65 | |
Basic fitting brand: | / | PLC: Siemens or Allen-Bradley Speed controller: Danfoss or Beckhoff Low voltage: Schneider Control panel: TUV or UL/CUL certified Other customization possible | |
PLC control panel
Pneumatic valves for basic automation
Copper outer cladding
